LIVOLO Smart Wi-Fi Thermostat — a comfortable temperature without constant monitoring

The LIVOLO Wi-Fi thermostat automatically maintains a comfortable temperature and allows you to control your heating from a smartphone. You no longer need to constantly switch the heating on and off or adjust it manually — simply create a convenient schedule once.

The thermostat can warm up the room before you wake up, lower the temperature when no one is at home, and switch the heating back on before you return. This helps reduce unnecessary electricity consumption without compromising comfort.

Control the temperature from your smartphone

With the LIVOLO mobile app, you can:

• switch the heating on and off remotely;

• check the current temperature;

• change the target temperature from anywhere;

• configure operating modes;

• create a separate schedule for each day of the week;

• activate the touch panel lock.

Even if you forget to switch off the heating, you can do it from your smartphone — there is no need to return home.

A personalised schedule for every day

The thermostat supports weekly programming, allowing you to set up to six temperature periods for each day. For example, the floor can be warm in the morning, the temperature can automatically decrease during the day, and the room can warm up again before you return home.

This mode is particularly convenient for underfloor heating, apartments, private houses, offices, shops, and premises with regular working hours.

Precise temperature control

The built-in sensor monitors the air temperature. The thermostat also supports the connection of up to two external NTC 10 kOhm or DS18B20 sensors. In the app, you can select which sensor readings should be used to control the heating.

This allows you to monitor not only the room temperature but also the floor temperature or another area. The temperature display increment is 0.5 °C, while the temperature compensation function allows you to adjust the sensor readings within a range of −9 to +9 °C.

Equipment protection and family safety

The thermostat is equipped with functions that make the heating system safer to use:

• overheat protection automatically disconnects the load if the temperature rises to a dangerous level;

• frost protection maintains a minimum level of heat when the temperature falls below the permitted level;

• child lock prevents accidental changes to the settings;

• fault indication alerts you to problems with the device;

• relay operation indicator shows when the heating system is active.

For use at night, the thermostat features a sleep mode and adjustable display brightness. After 15 seconds of inactivity, the panel automatically switches to standby mode.

Key benefits

• control via Wi-Fi and the LIVOLO app;

• weekly scheduling with six periods per day;

• «Home», «Away», and «Sleep» modes;

• automatic maintenance of the selected temperature;

• built-in sensor and support for two external sensors;

• temperature compensation;

• overheat and frost protection;

• touch panel lock;

• adjustable display brightness;

• cyclic heating control mode;

• 100–240 V, 50/60 Hz power supply;

• load capacity of up to 16 A for the live-output version or up to 3 A for the dry-contact version;

• power consumption of less than 0.8 W.

The LIVOLO Wi-Fi thermostat eliminates the need for daily heating control: it automatically maintains a comfortable temperature, operates according to your schedule, and helps prevent electricity from being wasted on heating an empty room.
